PREMIUM glasswasher 3.4 kW - with drain and cleaner pump, rinse aid supply & Wi-Fi option (double-walled)

Benefits

• WLAN system for sending text messages to communicate any anomalies or preventive messages about the dishwasher status and adjustments via remote control

• Electronic control with high-resolution TFT color display 45x60 mm with direct display of temperatures, phases and any anomalies

• Four changeable wash cycles for the different types of dishes to be washed

• The HY-NRG flush system with break tank, pressure boost pump and insulated boiler keeps the set temperature and flush water pressure constant

Design

• Premium dishwasher

• Double wall dishwasher with lye - and cleaner pump.

• Substructure device

• Tank and door made of high-quality stainless steel Stainless Steel AISI 304

• Fully printed tank with rounded corners and bottom inclined after the filters

• Insulated balanced door

• Integrated Wi-Fi connection system for remote control.

• 2 washing arms for effective cleaning

• With 2 rinse aid arms

• Electric rinse aid dispenser

• It is recommended to use an external descaler

• List of the number of daily and total wash cycles performed

Quality

• Double-walled body made of high-quality Stainless Steel AISI 304

• Wash arm and rinse aid arm made of stainless steel

• Very robust and energy saving

Rinsing

• with 4 cycles

• Rinse program I: Rinse time 60 Sekunden, 60 Baskets / hr

• Rinsing program II: Rinsing time 120 Sekunden, 30 Baskets / hr

• Rinsing program III: Rinsing time 180 Sekunden, 20 Baskets / hr

• Rinsing program IV: Rinsing time 480 Sekunden, 8 Baskets / hr

Technology

• Electrical rinse aid feed

• Cleaner tank with double filter system

• Rotating, non-clogging wash and rinse jets

• Stand-by mode for energy saving

• electric rinse aid dosage pump (white  hose)

• Lye pump pumps dirty water over a height difference into the sewage connection.

Connection

• Power: 3,40 kW

• Electrical connection: 230V / 1N/PE / 50 Hz

Dimensions

• Outer dimensions W x D x H: 473 mm x 539 mm x 700 mm

Includes

• 1x universal basket

• 1x dish rack

• 1x cutlery basket

• 1x water inlet hose

• 1x water drain hose

• 1x hose for rinse aid with float

• 1x Hose for detergent (Red)

• 1 Schuko plug

Standards

• Manufactured in accordance with relevant hygiene and safety standards

• CE marking as proof of conformity with EU regulatory standards

• Materials comply with European food safety standards

Please note:

• WI-FI module stores HACCP parameters, such as cycles, temperatures, alarms. These parameters can be downloaded via smartphone close connection or via a dedicated website.

• Information on the supply voltage can be found in the user manual

• Please note that a cold water connection is required for this unit.

• Only suitable for chlorine free detergents.

• For optimal rinsing, we recommend that you regularly descale the unit and its components!

• If you have used a descaler upstream, note that after approx. 1500 - 2000 water flow rate the cartridge must be regenerated. The actual maximum flow rate depends on the water hardness.
