PREMIUM glasswasher 3.4 kW - with drain and cleaner pump, rinse aid supply & Wi-Fi option (double-walled)
Code: D9784355Related products
Product detailed description
Benefits
- WLAN system for sending text messages to communicate any anomalies or preventive messages about the dishwasher status and adjustments via remote control
- Electronic control with high-resolution TFT color display 45x60 mm with direct display of temperatures, phases and any anomalies
- Four changeable wash cycles for the different types of dishes to be washed
- The HY-NRG flush system with break tank, pressure boost pump and insulated boiler keeps the set temperature and flush water pressure constant
Design
- Premium dishwasher
- Double wall dishwasher with lye - and cleaner pump.
- Substructure device
- Tank and door made of high-quality stainless steel Stainless Steel AISI 304
- Fully printed tank with rounded corners and bottom inclined after the filters
- Insulated balanced door
- Integrated Wi-Fi connection system for remote control.
- 2 washing arms for effective cleaning
- With 2 rinse aid arms
- Electric rinse aid dispenser
- It is recommended to use an external descaler
- List of the number of daily and total wash cycles performed
Quality
- Double-walled body made of high-quality Stainless Steel AISI 304
- Wash arm and rinse aid arm made of stainless steel
- Very robust and energy saving
Rinsing
- with 4 cycles
- Rinse program I: Rinse time 60 Sekunden, 60 Baskets / hr
- Rinsing program II: Rinsing time 120 Sekunden, 30 Baskets / hr
- Rinsing program III: Rinsing time 180 Sekunden, 20 Baskets / hr
- Rinsing program IV: Rinsing time 480 Sekunden, 8 Baskets / hr
Technology
- Electrical rinse aid feed
- Cleaner tank with double filter system
- Rotating, non-clogging wash and rinse jets
- Stand-by mode for energy saving
- electric rinse aid dosage pump (white hose)
- Lye pump pumps dirty water over a height difference into the sewage connection.
Connection
- Power: 3,40 kW
- Electrical connection: 230V / 1N/PE / 50 Hz
Dimensions
- Outer dimensions W x D x H: 473 mm x 539 mm x 700 mm
Includes
- 1x universal basket
- 1x dish rack
- 1x cutlery basket
- 1x water inlet hose
- 1x water drain hose
- 1x hose for rinse aid with float
- 1x Hose for detergent (Red)
- 1 Schuko plug
Standards
- Manufactured in accordance with relevant hygiene and safety standards
- CE marking as proof of conformity with EU regulatory standards
- Materials comply with European food safety standards
Please note:
- WI-FI module stores HACCP parameters, such as cycles, temperatures, alarms. These parameters can be downloaded via smartphone close connection or via a dedicated website.
- Information on the supply voltage can be found in the user manual
- Please note that a cold water connection is required for this unit.
- Only suitable for chlorine free detergents.
- For optimal rinsing, we recommend that you regularly descale the unit and its components!
- If you have used a descaler upstream, note that after approx. 1500 - 2000 water flow rate the cartridge must be regenerated. The actual maximum flow rate depends on the water hardness.
Additional parameters
Category: | Bases of glass washers |
---|---|
Weight: | 39 kg |
Hloubka: | 539 mm |
Hmotnost: | 39.000 kg |
Hmotnost balení: | 50 kg |
Šířka: | 473 mm |
Výkon: | 3,40 kW |
Výška: | 700 mm |
